CNC MACHINING CENTER EQUIPMENT

Matsuura MAM 72-100 5axis (full) machining center

12,000 RPM Spindle, “X” 42” travel, 36 “Y” travel, 38” “Z” travel.

25” Dual Pallets 150 tools 50 Taper



(8) DVF 5000 Doosan 5-Axis Vertical Machining Center

5-axis machine with probes

X axis 24.6” / Y axis 17.71” / Z axis 15.50”

Full 5-axis simultaneous moves



Doosan NHM8000 horizontal machining center

Travels:
X= 55.1”

Y= 41.3”

Z= 47.2”

Full 4th axis, 90 tool ATC, twin 31.5” pallets 50 Taper

3 speed gear box spindle



Doosan NHM6300 Horizontal Machining Center

Travels:
X= 41.35”

Y= 33.46”

Z= 39.37”

Full 4th axis, 90 tool ATC, twin 25” pallets

3 speed gear box spindle

(2)  Johnford AHC 1600 Horizontal Mill

Travels:
X= 63”

Y= 50”

Z= 40”

40 tool ATC, twin 31.5” Diameter 4th axis

2 speed gear box spindle



KIWA KH-55 #50 Horizontal Machining Center (Cat 50 Taper)

Travels, X 31.5”, Y 31.5”, Z 31.5” full 4th axis.

10,000 RPM Spindle / 120 tool capacity



Feeler VMP-1100 Liner Guideway Vertical Machining Center

Max. Work piece X43.3" Y24" Z 23.6" with 4th axis

10,000 RPM Spindle / 40 tool capacity



Feeler HV-1000 Vertical Machining Center

with Roller Guide Way's on X and Y axis and Glass Scales

Max. Work piece X39.4" Y20.5" Z19.9" 4th axis.

15,000 RPM Spindle / 40 tool capacity



Kitamura Mycenter 4

5-axis machine with probes

X axis 24” / Y axis 24” / Z axis 19.7”

Full 5-axis simultaneous moves



Doosan Mynx 5400 Vertical Machining Center

3-axis machine

50 taper gear box spindle

X axis 40.2” / Y axis 21.3” / Z axis 20.9”



Mitsubishi TV500

Max. Work X 19.7”, Y 15.7”, Z 13” 4th Axis

24,000 RPM, 21 Tool Capacity



CNC TURNING EQUIPMENT

Honor Seiki CNC VTL 100

850 RPM Spindle w/ 40” Hydraulic Chuck 60 HP

X Axis 24.6” / Z axis 39.37”
48” Swing / 43” Max Cutting Diameter / 26” Height



Hwacheon HI-TECH700 High Performance CNC Lathe

1800 RPM Spindle w/18" Chuck and 5.9" dia. tailstock (MT#5)

X axis 27.5" / Z axis 78.7" Travel

Max turning dia 34” diameter



(2) Feeler FTC-200L Liner Guideway Turning Centers

2.6" Bar Capacity / 4,500RPM 25HP Spindle Motor

X axis 6.9+1" / Z axis 27.6 Z Travel

Doosan Puma 400 CNC Turning Center

18” Chuck, 2 speed Gearbox, 43.5” Z



(5) Doosan Puma 300 CNC Turning Center

12” Chuck, 2 speed, Gearbox, 24” swing 36” Z

(3) currently in facility

Leadwell LTC-25ALM CNC Turning Center

12” chuck, Gearbox driven machine.

Swing 24” / Z axis 42.9" Travel



Doosan Puma V8300 VTL

24” chuck, Gearbox driven machine.

Swing 36” / Z axis 18" Travel



Nakamura Tome TMC20 CNC Turning Center

12' bar feed 2" Bar Capacity / 3,000RPM

HEAT TREAT EQUIPMENT

ISPEN Vacuum Furnace with Moly Hot Zone

Hot zone size 18” high, 24” wide, 36” deep

Max Temp 2250°F

ISPEN Vacuum Furnace

Hot zone size 36” high, 36” wide, 48” deep

Max Temp 2250°F



Air Oven

(electric 550 degrees’ capacity) 18” x 24”



Air Oven

1400 degrees’ capacity 12” x 24”



Chemical Vapor deposition “CVD” aluminide coating

Aeromet CVD coating system 32” diameter by 29” height hot zone capability

Furnace is capable of 2200 F temperature



METAL SPRAY EQUIPMENT

Praxair TAFA 9910 CoArc Twin Wire Arc Spray Console

Praxair TAFA 9935 Arc Wire Gun

Metco 5P-II Combustion Powder Thermospray Gun

Metco 12E Combustion Wire Thermospray Gun

350lb Capacity Turntable with 90° Tilt Function

FANUC M-10iA 6-Axis Robot

MANUAL EQUIPMENT

YAM 24" Gap Engine Lathe

(2) Ganesh 3 axis Manual Mill

(1) Excel 3 axis Manual Mill

(1) Proto Trak FH7 3 axis vertical milling machine CNC



EDM EQUIPMENT

(3) Sodick 750LH

(LN2WH) Linear Motor – Wire Electrical Discharge Machine

Travels of 29.53” (X) 19.68” (Y) 24.00” (Z) 30.31” (U) 20.47” (V)



Sodick AG600L

(LN2W) Linear Motor - Wire Electrical Discharge Machine

Travels of 23.62" (X), 15.75" (Y), 13.78" (Z) and 4.72" (U/V)

Sodick AG60L

Linear Motor Driven, High Speed, High-Performance CNC Sinker EDM

29.53" X 19.69" Work Table

(2)  Makino EDBV8 CNC EDM hole drilling machine

5 axis (Both Letters)

Travels

X=31.5”

Y=23.62

Z= 29.52

24 station tool changer

Touch probe kit

150Kg max work piece weight.

Diffusion hole capabilities





Current CT400

Hole popper with full 4th axis capability

AIR FLOW EQUIPMENT



Flow Systems

Mass air flow test stand. High flow configuration using sonic nozzles. Part pressure ratio range 1.0128 to 2.36 (.18 – 20 psig).  12” dia. Plenum cart.



WELDING EQUIPMENT

(1) Hamilton Standard Electron Beam Welder

Chamber size 52 x 42 x 36 model W2

(1) Miller GTAW model Synchrowave 350



GRINDING EQUIPMENT

(2) Heald 273 A I.D. Grinder (With multiple red head spindles)

Harig Super 612 Surface Grinder



COMPUTER EQUIPMENT

Mastercam V9 programming software

SolidWorks Professional 2012



PARTIAL LIST OF INSPECTION EQUIPMENT

Global Advantage 9.12.8 CMM

CDMIS 2015.1 CAD++, Scanning enabled



Sheffield Pioneer CMM 6.8.6

PC-DMIS CAD++ Software, Pioneer Touch Trigger System



TESA Scope 355H Optical Comparator w/ TS 200 Technology

TESA Hite 400 Height Gage

(4) Granite surface plates sizes   5’ x 5’

Micrometers to 30”

Bore gages .20 - 12.00 diameter

Set-up blocks, vee blocks

81 piece gage block sets

Height masters, height gages

Thread gages, ring gages

Pin gages .011 to 1.000 diameter

LIQUID PENETRANT INSPECTION (FPI)

Certified to ASTM-E-1417, Type 1 Fluorescent Penetrant, Method D, Sensitivity Level 4



 Honeycomb Seal Brazing Capabilities

All Tacking, Brazing, Inspection equipment to produce Honeycomb Seals up to 24” Diameter

Hexagon Global S Green 7.10.7

PC-DMIS CAD ++, Scanning enabled

Measuring Range:

X-Axis: 28”

Y-Axis: 40”

Z-Axis: 25”



Zeiss Eclipse 2840-24

Calypso, Renishaw PH9 Probing System

Measuring Range:

X-Axis: 28”

Y-Axis: 40”

Z-Axis: 24”



Mitutoyo PH-A14 Optical Comparator



 Zeiss Surfcom 1500SD Profilometer



MISCELLANEOUS EQUIPMENT

(6) downdraft deburring benches

(1) Torit dust collection systems

Auto-Chlor System A4 Parts washer

(2) Zero pulsarm Grit Blast cabinets 36” capacity

Arbor and hydraulic presses

Overhead automatic Konecrane 3 ton capacities

Kalamazoo 5hp horizontal band saw 14”x14” capacity 1-1/2” blade

150 HP Air Compressor with Dryer
